SKF 6308-2Z Deep Groove Ball Bearing

Manufacturer: SKF Mfr. Part No.: 6308-2Z Deep Groove Metric Ball Bearings - Shielded Shielded (2Z) bearings are fitted with two metal dust shields to prevent the ingress of dirt and foreign matter. 2RZ bearings are 2Z bearings fitted with two low friction seals. Deep groove ball bearings are versatile and robust in operation, they also require little maintenance. Deep groove ball bearings are the most widely used bearing type due to their simple design and suitability for high speeds. Features and Benefits • Primarily intended for applications where the bearing inner ring rotates • If the outer ring rotates there is a danger that grease may be lost from the bearing at high speeds • Both standard and C3 clearance available Specifications Attribute Value Inside Diameter 40mm Outside Diameter 90mm Ball Bearing Type Deep Groove Race Width 23mm End Type Shielded Number of Rows 1 Static Load Rating 24kN Material Steel Cage Material Steel Race Type Plain Dynamic Load Rating 42.3kN Bore Type Parallel
