IXYS *IXYS MCC312-16IO1, Dual Thyristor Module 1600V, 320A 150mA

Manufacturer: IXYS Mfr. Part No.: MCC312-16IO1 MCC Series Dual series thyristors Approvals UL recognised component Thyristors - IXYS A Thyristor is a solid-state semiconductor device with four layers of alternating N and P-type material. They act as bistable switches, conducting when their gate receives a current trigger, and continue to conduct while they are forward biased. Thyristors are synonymous to Silicon-Controlled Rectifier (SCR). Encapsulated modules with electrically isolated base plate. Suitable for applications such as battery chargers, welders and plating equipment, regulated power supplies and temperature and speed control circuits. Specifications Attribute Value Rated Average On-State Current 320A Thyristor Type SCR Module Package Type Y1 CU Repetitive Peak Reverse Voltage 1600V Surge Current Rating 10.1kA Mounting Type Panel Mount Maximum Gate Trigger Current 150mA Maximum Gate Trigger Voltage 2V Maximum Holding Current 150mA Pin Count 7 Dimensions 115 x 50 x 49mm Maximum Operating Temperature +140 °C Repetitive Peak Off-State Current 40mA Peak On-State Voltage 1.32V Repetitive Peak Forward Blocking Voltage 1600V Minimum Operating Temperature -40 °C
