FAG 31308-XL 40mm I.D Taper Roller Bearing

Manufacturer: FAG Mfr. Part No.: 31308-XL High radial loads occur High axial loads act on one side Combined loads must be supported (radial and axial forces acting simultaneously) Precise axial guidance of the shaft is required (locating bearing function) The bearing arrangement must have very high axial rigidity The bearing position is operated clearance-free or under preload (single bearings are adjusted against each other) High running accuracy is required The load carrying capacity of angular contact ball bearings is no longer sufficient and the higher speed suitability of angular contact ball bearings is not required The bearings are not required to compensate misalignments The design objective comprises compact, rigid and economical bearing arrangements with a high load carrying capacity Specifications Attribute Value Inside Diameter 40mm Outside Diameter 90mm Roller Bearing Type Taper Race Width 25.25mm Bore Type Tapered Static Load Rating 83000N Cage Material Sheet Steel Number of Rows 1 Dynamic Load Rating 89000N End Type Open Fatigue Limit Load 12400N
