EPCOS B32332 Series Polypropylene Film Capacitors

EPCOS B32332 Polypropylene Film Capacitor, 450V ac, ±5%, 25μF, Stud Mount The B32332 series of film capacitors from EPCOS are constructed from metallised polypropylene film encapsulated in an aluminium can with plastic cap. Featuring a low dissipation factor and excellent self-healing properties, these film capacitors provide high insulation resistance and an overpressure disconnection device. B32332 film capacitors are ideal for sine wave applications and motor run applications. Double fast on terminals Rated for continuous service Option threaded studs are Standards IEC 60252-1 2001-02, EN 60252 2001, UL 810 For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply. Standards IEC 60252-1 2001-02, EN 60252 2001, UL 810 Specifications Attribute Value Capacitance 25µF Voltage 450V ac Mounting Type Stud Mount Tolerance ±5% Series B32332 Height 93mm Dimensions 35 (Dia.) x 93mm Dielectric Polypropylene Terminal Type Stud Mount Minimum Operating Temperature -25°C Maximum Operating Temperature +85°C
